Updated in 4.97

​
Description

This Node uses a Large Language Model (LLM) to extract entities, such as product codes, booking codes, or customer IDs, from input.text of the Input object. The Node supports both chat and voice use cases by processing text and transcribed speech inputs. Before using this Node, set the LLM provider in the Settings. You can configure the Node to either use the default model defined in the Settings or choose a specific configured LLM. To view the extracted entity in the Interaction Panel, activate debug mode. To output the extracted entity, add a Say Node below the LLM Entity Extract Node in the Flow editor. In the Text field of the Say Node, use the key you specified in the Storage Options section, for example, {{input.extractedEntity}}.

​
Parameters

ParameterTypeDescription
Large Language ModelListSelect a model or use the default one.
Entity NameCognigyScriptThe name of the entity to extract. For example, customerID.
Entity DescriptionCognigyScriptA sentence that describes the entity. For example, An alphanumeric string of 6 characters, e.g., ABC123 or 32G5FD.
Example InputTextExamples of text inputs. For example, My ID is AB54EE, is that ok?, That would be ah bee see double 4 three, I guess it's 49 A B 8 K. Alternatively, you can click Show JSON Editor and add input examples in the code field.
Extracted EntityCognigyScriptExamples of extracted entities. For example, AB54EE, ABC443, 49AB8K.
ParameterTypeDescription
TemperatureIndicatorThe appropriate sampling temperature for the model. Higher values mean the model will take more risks.
TimeoutNumberThe maximum number of milliseconds to wait for a response from the LLM provider.
Response FormatSelectChoose the format for the model’s output result. You can select one of the following options:
  • None — No response format is specified. Use this option if the LLM provider doesn’t accept the response format you’re using, or if you want to use the provider’s default format. This option is selected by default.
  • Text — the model returns messages in text format.
  • JSON Object — the model returns messages in JSON format. In contrast to the LLM Prompt Node, this Node is already instructed to generate a JSON output when this option is selected Note that not all LLMs support this format, which may cause model calls to fail. For more information, refer to the LLM provider’s API documentation.
ParameterTypeDescription
How to handle the resultSelectDetermine how to handle the prompt result:
  • Store in Input — stores the result in the Input object.
  • Store in Context — stores the result in the Context object.
Input Key to store ResultCognigyScriptThe parameter appears when Store in Input is selected. The result is stored in the extractedEntity Input object by default. You can specify another key.
Context Key to store ResultCognigyScriptThe parameter appears when Store in Context is selected. The result is stored in the extractedEntity Context object by default. You can specify another key.
When using the Interaction Panel, you can trigger two types of debug logs. These logs are only available when using the Interaction Panel and aren’t intended for production debugging. You can also combine both log types.
ParameterTypeDescription
Show Token CountToggleSend a debug message containing the input, output, and total token count. The message appears in the Interaction Panel when debug mode is activated. Cognigy.AI uses the GPT-3 tokenizer, so actual token usage may vary depending on the model. The parameter is inactive by default.
Log Request and CompletionToggleSend a debug message containing the LLM provider and the subsequent completion. The message appears in the Interaction Panel when Debug Mode is enabled. The parameter is inactive by default.

​
Examples

The user input is stored under input.text:
Hello, my booking code is XYZ987. Can you confirm my reservation?
LLM Entity Extract Node configuration:
  • Entity Name: bookingCode
  • Entity Description: An alphanumeric booking code of 6 characters, e.g., XYZ123 or ABC987
  • Example Input:
    • My booking code is XYZ123.
    • It’s X Y Z 1 2 3.
  • Extracted Entity:
    • XYZ123
The extracted entity is stored under input.extractedEntity:
XYZ987
The user input is stored under input.text:
I’d like to order the product with code P45K2Q. Can you add it to my cart?
LLM Entity Extract Node configuration:
  • Entity Name: productCode
  • Entity Description: An alphanumeric product code, e.g., P12A3B or X45K2Q
  • Example Input:
    • The product code is P12A3B.
    • That would be P 1 2 A 3 B.
  • Extracted Entity:
    • P12A3B
The extracted entity is stored under input.extractedEntity:
P45K2Q

​
