Description

This Node is in legacy mode, which means it is deprecated. Use a new version of this Node to get more flexibility when building AI Agents.
The LLM Prompt Node lets you use prompts with different LLM models to generate text or structured content. Before using this Node, set the LLM provider in the Settings. The Node supports the following modes:
  • Chat. This mode is activated by default and is preferable for dynamic conversations and interactions with the model. It takes into account the context of messages from the user and the agent, depending on the chosen number of transcript turns (messages) in the Transcript Turns setting.
  • Prompt. This mode is preferable for single-turn tasks or generating text based on a single prompt.
If your LLM provider doesn’t support Chat mode, Cognigy.AI automatically converts the Chat request to a Prompt request.

​
Parameters

​
Large Language Model

The selected Default model is the model that you specified in Settings > Generative AI Settings of your Project. You can select a different model from the list or override the selected model using the Custom Model Options parameter.

​
Instruction

This is either the prompt for completions or the system message for chat. Additionally, you can inject the recent conversation into the Instruction (System Message/Prompt) field by using these tags:
  • @cognigyRecentConversation — the tag is replaced with a string that can contain up to 10 recent AI Agent and 10 user outputs, for example:
    Bot: agentOutput1
User: userOutput1
Bot: agentOutput2
User: userOutput2
  • @cognigyRecentUserInputs — the tag is replaced with a string that can contain up to 10 recent user outputs, for example:
    User: userOutput1
User: userOutput2
    If you want to access only the last user input, specify the Text token in the Instruction (System Message/Prompt) field.
When adding a tag, ensure that you leave a line break before and after the tag, for example:
A user had a conversation with a chatbot. The conversation history so far is:
@cognigyRecentConversation

Describe the user sentiment in one very short line.
Both tags can include an optional turn limit parameter, which is appended to the tag. Examples:
@cognigyRecentConversation:3 // returns the last 3 turns of the conversation.
@cognigyRecentUserInputs:2 // returns the last 2 user inputs.

​
Chat Mode

Activate the toggle to enable Chat mode.
ParameterTypeDescription
Sampling MethodSelectMethods:
  • Temperature — determines the level of randomness in the generated text. A higher temperature allows for more diverse and creative outputs, while a lower temperature leads to more predictable and consistent outputs with the training data.
  • Top Percentage — specifies the percentage of the most probable outputs for generation, resulting in more consistent output.
Maximal TokensIndicatorThe maximum number of tokens to generate in the completion.
Presence PenaltyIndicatorNumber between -2.0 and 2.0. Positive values penalize new tokens based on whether they appear in the text so far, increasing the model’s likelihood of talking about new topics.
Frequency PenaltyIndicatorNumber between -2.0 and 2.0. The penalty assigns a lower probability to tokens frequently appearing in the generated text, encouraging the model to generate more diverse and unique content.
Use StopsToggleWhether to use a list of stop words to let Generative AI know where the sentence stops.
StopsTextUp to 4 sequences where the API will stop generating further tokens. The returned text will not contain the stop sequence.
TimeoutNumberThe maximum number of milliseconds to wait for a response from the Generative AI Provider.
Response FormatSelectChoose the format for the model’s output result. You can select one of the following options:
  • None — no response format is specified, or do not request with an LLM provider that does not accept any response format or does not support it or could use provider’s default in-built response format. This option is selected by default.
  • Text — the model returns messages in text format.
  • JSON Object — the model returns messages in JSON format. To use this option, instruct the model to generate JSON via a system or user message in the Instruction (System Message/Prompt) field. For example, Take the user message and return it as JSON in the following format {"message": "THE_MESSAGE"}. Note that this parameter may not be supported by all LLMs. For more information, refer to the LLM provider’s API documentation.
SeedNumberUse this parameter for consistent output when referring to the same LLM Prompt Node multiple times. Specify any integer number, for example, 123. The number in the Seed field and the prompt in the Instruction (System Message/Prompt) field should remain unchanged during subsequent references to the Node.
Note that in OpenAI, this parameter is in Beta and is supported only by certain models.
ParameterTypeDescription
How to handle the resultSelectDetermine how to handle the prompt result:
  • Store in Input — stores the result in the Input object. To print the prompt result, use the LLM Prompt Result Token in the Say Node or enable the Output result immediately option.
  • Store in Context — stores the result in the Context object. To print the prompt result, use the LLM Prompt Result Token in the Say Node or enable the Output result immediately option.
  • Stream to Output — streams the result directly into the output. This means that the model provides prompts directly into the conversation chat, as soon as a Stream Buffer Flush Token is matched, and you don’t need to use the LLM Prompt Result token and Say Node. By default, this result won’t be stored in either the Input or the Context. You can change this behavior by activating the Store Copy in Input option. Note that streaming may not be supported by all Cognigy LLM Prompt Node providers, such as Google1. If streaming is not supported, enabling the Store Copy in Input option will save the result to the Input object.
Input Key to store ResultCognigyScriptThe parameter appears when Store in Input is selected. The result is stored in the promptResult Input object by default. You can specify another key.
Context Key to store ResultCognigyScriptThe parameter appears when Store in Context is selected. The result is stored in the promptResult Context object by default. You can specify another key.
Stream Buffer Flush TokensText ArrayThe parameter appears when Stream to Output is selected. It defines tokens that trigger the stream buffer to flush to the output. The tokens can be punctuation marks or symbols, such as \n.
Stream Buffer Flush OverridesText ArrayThe parameter appears when Stream to Output is selected. It allows using regular expressions (without leading or trailing slashes) to control stream buffer flushing. A trailing $ is automatically added to match patterns at the end of the buffer. For example, \d+\. checks for a number followed by a dot at the end of the string.
Output result immediatelyToggleThe parameter appears when you select either Store in Input or Store in Context. This parameter allows you to output results immediately without using the Say Node and LLM Prompt token.
Store Detailed ResultsToggleThe parameter appears when you select either Store in Input or Store in Context, or when you enable Store Copy in Input. This parameter allows you to save detailed results of the LLM’s generated output. By default, the result is stored in the promptResult object. You can specify another value in the Context Key for the Result field to save it in the Context object, or in the Input Key for the Result to save it in the Input object. The object contains keys such as result, finishReason, and usage. It may also include detailedResult if completion models are used, as well as firstChunk and lastChunk in some streaming results, depending on the LLM provider.
Store Copy in InputToggleThe parameter appears when Stream to Output is selected. In addition to streaming the result to the output, store a copy in the Input object by specifying a value in the Input Key to store Result field.
Input Key to store ResultCognigyScriptThe parameter appears when Store Copy in Input is selected. The result is stored in the promptResult Input object by default. You can specify another key.
Streaming ResultsIn Stream mode, LLM generates tokens and returns them one by one to Cognigy.AI to ensure low-latency responses. Cognigy.AI monitors delimiter tokens (Stream Buffer Flush Tokens), which serve as markers indicating when to output the token buffer. These tokens could be ., !, ?, or any other symbols that act as delimiters for complete logical statements. When Cognigy.AI detects one of these tokens, it promptly flushes the token buffer into the voice or text chat.The preconfigured overrides are listed in the table.
RegexDescriptionExample
\d+\.A number followed by a dot.26.08
\b(?:Dr|Ms|Mr|Mrs|Prof|Sr|Jr|ca)\.Common abbreviations followed by a dot.Mr.
\b[A-Z]\.A single capital letter followed by a dot.M. Smith
\.\.\.Three dots used for omission.…
\b.\..\.Two-letter abbreviations.i.e., e.g.
ParameterTypeDescription
Log to System LogsToggleLog errors to the system logs. They can be viewed on the Logs page of your Project. The parameter is inactive by default.
Select Error Handling ApproachSelectYou can select one of the Error Handling options:
  • Stop Flow Execution — terminate the current Flow execution.
  • Continue Flow Execution — allow the Flow to continue executing, bypassing the error and proceeding to the next steps.
  • Go to Node — redirect the workflow to a specific Node in the Flow, which can be useful for error recovery or customized error handling.
Error Message (optional)TextThe parameter appears when Continue Flow Execution is selected. Add an message to output if the LLM Prompt Node fails.
Select FlowSelectThe parameter appears when Go to Node is selected. Select a Flow from the available options.
Select NodeSelectThe parameter appears when Go to Node is selected. Select a Node from the available options.
These settings are helpful if you need to use parameters that are not included in the LLM Prompt Node or if you need to overwrite existing ones.
ParameterTypeDescription
Custom Model OptionsJSONAdditional parameters for the LLM model. You can specify individual parameters as well as entire functions. These parameters customize the behavior of the model, such as adjusting temperature, top_k, or presence_penalty. Note that if you use a parameter already set in the Node, for example, temperature, it will be overwritten. To view the full list of available parameters for your model, refer to the LLM provider’s API documentation. For example, OpenAI or Azure OpenAI.

Examples:
  • { "logprobs": true }
  • { "temperature": 0.7 }
  • { "model": "claude-3-5-sonnet-20240620" } (see Forcing Model Versions)
Custom Request OptionsJSONAdditional parameters for the LLM request. These parameters customize the request itself, such as setting parameters related to timeout, retries, or headers. For more information, refer to the LLM provider’s API documentation.

Examples:
- { "timeout": 5000 }
- { "headers": { "Authorization": "Bearer <token>" } }
Forcing Model VersionsYou can force the LLM Prompt Node to use a specific model version by including it in the Custom Model Options. This means that the LLM Prompt Node will use the specified version of the language model instead of the default or any other available versions. This allows for more control over the behavior of the LLM Prompt Node, ensuring it utilizes the desired model version for generating prompts or responses.You can use models from any LLM provider supported by Cognigy, including those not yet directly integrated. However, you can only replace one model with another within the same provider.Let’s consider an example with the Anthropic provider: how to force the LLM Prompt Node to use the model version claude-3-sonnet-20240229, despite the LLM resource defaulting to the claude-3-5-sonnet-20240620 model:
  1. Create an Anthropic LLM resource for Claude-1, for example, claude-3-5-sonnet-20240620.
  2. Create a Flow and add an LLM Prompt Node to it.
  3. In the LLM Prompt Node, select the model claude-3-5-sonnet-20240620 from the Large Language Model list.
  4. Override the model selection. In the Custom Model Options field, specify the custom model options as follows: { "model": "claude-3-sonnet-20240229" }.
  5. Click Save Node.
The LLM Prompt Node now utilizes the claude-3-sonnet-20240229 model.Below, you’ll find documentation for supported models:
When using the Interaction Panel, you can trigger two types of debug logs. These logs are only available when using the Interaction Panel and are not intended for production debugging. You can also combine both log types.
ParameterTypeDescription
Show Token CountToggleSend a debug message containing the input, output, and total token count. The message appears in the Interaction Panel when debug mode is enabled. Cognigy.AI uses the GPT-3 tokenizer algorithm, so actual token usage may vary depending on the model used. The parameter is inactive by default.
Log Request and CompletionToggleSend a debug message containing the request sent to the LLM provider and the subsequent completion. The message appears in the Interaction Panel when debug mode is enabled. The parameter is inactive by default.

​
More Information

1: Note that not all LLM models support streaming.
