LLM Prompt

Description

The LLM Prompt Node lets you configure the system prompt for your LLM calls, generating both text and structured content. With this Node, you can also:

Include tools in your LLM calls.
Enable image handling.
Set advanced LLM request options.

Additionally, you can refer to your AI Agent configuration using the Load AI Agent Node. Before using this Node, set the LLM provider in the Settings.

LLM Prompt Settings

Large Language Model

The selected Default model is the model that you specified in Settings > Generative AI Settings of your Project.You can select a different model from the list or override the selected model using the Custom Model Options parameter.

System Prompt

The system prompt is the message sent to the LLM to guide its responses. The parameter supports CognigyScript, allowing dynamic content and logic within the prompt. This prompt can work either as the input for completion tasks or as the system message in chat-based interactions, setting context and behavior for the AI Agent.Additionally, you can inject the recent conversation into the System Prompt field by using these tags:

@cognigyRecentConversation — the tag is replaced with a string that can contain up to 10 recent AI Agent and 10 user outputs, for example:
```
Bot: agentOutput1
User: userOutput1
Bot: agentOutput2
User: userOutput2
```
@cognigyRecentUserInputs — the tag is replaced with a string that can contain up to 10 recent user outputs, for example:
```
User: userOutput1
User: userOutput2
```

If you want to access only the last user input, specify the Text token in the System Prompt field.When adding a tag, ensure that you leave a line break before and after the tag, for example:

A user had a conversation with a chatbot. The conversation history so far is:
@cognigyRecentConversation

Describe the user sentiment in one very short line.

Both tags can include an optional turn limit parameter, which is appended to the tag.Examples:

@cognigyRecentConversation:3 // returns the last 3 turns of the conversation.
@cognigyRecentUserInputs:2 // returns the last 2 user inputs.

Advanced

Parameter	Type	Description
Maximal Tokens	Slider	The maximum number of tokens to generate in the completion.
Use Single Prompt Mode	Toggle	Send a single prompt to the model without any conversation context. This parameter is disabled by default. It doesn’t support multi-turn conversations or chat and is useful for simple, one-off completions.
Transcript Turns	Slider	The number of conversation turns to include in the LLM chat completion request. By default, the value is `50`.
Response Format	Select	Choose the format for the model’s output result. You can select one of the following options: None — no response format is specified, or do not request with an LLM provider that does not accept any response format or does not support it or could use provider’s default in-built response format. This option is selected by default. Text — the model returns messages in text format. JSON Object — the model returns messages in JSON format. To use this option, instruct the model to generate JSON via a system or user message in the Instruction (System Message/Prompt) field. For example, `Take the user message and return it as JSON in the following format {"message": "THE_MESSAGE"}`. Note that this parameter may not be supported by all LLMs. For more information, refer to the LLM provider’s API documentation.
Timeout	Number	The maximum number of milliseconds to wait for a response from the Generative AI Provider.
Sampling Method	Select	Methods: Temperature — determines the level of randomness in the generated text. A higher temperature allows for more diverse and creative outputs, while a lower temperature leads to more predictable and consistent outputs with the training data. Top Percentage — specifies the percentage of the most probable outputs for generation, resulting in more consistent output.
Temperature	Slider	Define the sampling temperature, which ranges between 0 and 1. Higher values, such as 0.8, make the output more random, while lower values, such as 0.2, make it more focused and deterministic.
Top Percentage	Slider	Control the Top-p (nucleus) sampling, ranging from 0 to 1. Higher values allow more diverse word choices, while lower values make the output more focused. For example, 0.9 means the model selects from the smallest set of words with a combined probability of 90%.
Presence Penalty	Slider	Number between -2.0 and 2.0. Positive values penalize new tokens based on whether they appear in the text so far, increasing the model’s likelihood of talking about new topics.
Frequency Penalty	Slider	Number between -2.0 and 2.0. The penalty assigns a lower probability to tokens frequently appearing in the generated text, encouraging the model to generate more diverse and unique content.
Use Stops	Toggle	Whether to use a list of stop words to let Generative AI know where the sentence stops.
Stops	Text	Up to 4 sequences where the API will stop generating further tokens. The returned text will not contain the stop sequence.
Seed	Number	Use this parameter for consistent output when referring to the same LLM Prompt Node multiple times. Specify any integer number, for example, `123`. The number in the Seed field and the prompt in the Instruction (System Message/Prompt) field should remain unchanged during subsequent references to the Node. Note that in OpenAI, this parameter is in Beta and is supported only by certain models.
Include Rich Media Context	Toggle	Controls whether context is added to the prompt. In this case, context refers to text extracted from rich media such as Text with Buttons, Quick Replies, and other types. This text provides AI Agents with additional information, improving their responses. If the Textual Description parameter in the Say, Question, or Optional Question Node is filled, the context is taken only from this parameter. If the Textual Description parameter is empty, the context is taken from the button titles and alt text in the rich media. By default, the Include Rich Media Context parameter is active. When this parameter is inactive, no context is added. Examples: If Textual Description is filled: Textual Description: `Select your preferred delivery option: Standard Delivery or Express Delivery`. Quick Replies’ buttons: `Standard Delivery`, `Express Delivery`. Context added to the prompt: `Select your preferred delivery option: Standard Delivery or Express Delivery`. If Textual Description is empty: Textual Description: empty. Quick Replies’ buttons: `Standard Delivery`, `Express Delivery`. Context added to the prompt: `Standard Delivery`, `Express Delivery`. If Include Rich Media Context is inactive: No context is added to the prompt.

Storage & Streaming Options

Parameter	Type	Description
How to handle the result	Select	Determine how to handle the prompt result: Store in Input — stores the result in the Input object. To print the prompt result, use the LLM Prompt Result Token in the Say Node or enable the Output result immediately option. Store in Context — stores the result in the Context object. To print the prompt result, use the LLM Prompt Result Token in the Say Node or enable the Output result immediately option. Stream to Output — streams the result directly into the output. This means that the model provides prompts directly into the conversation chat, as soon as a Stream Buffer Flush Token is matched, and you don’t need to use the LLM Prompt Result token and Say Node. By default, this result won’t be stored in either the Input or the Context. You can change this behavior by activating the Store Copy in Input option. Note that streaming may not be supported by all Cognigy LLM Prompt Node providers, such as Google¹. If streaming is not supported, enabling the Store Copy in Input option will save the result to the Input object.
Input Key to store Result	CognigyScript	The parameter appears when Store in Input is selected. The result is stored in the `promptResult` Input object by default. You can specify another key.
Context Key to store Result	CognigyScript	The parameter appears when Store in Context is selected. The result is stored in the `promptResult` Context object by default. You can specify another key.
Stream Buffer Flush Tokens	Text Array	The parameter appears when Stream to Output is selected. It defines tokens that trigger the stream buffer to flush to the output. The tokens can be punctuation marks or symbols, such as `\n`.
Stream Buffer Flush Overrides	Text Array	The parameter appears when Stream to Output is selected. It allows using regular expressions (without leading or trailing slashes) to control stream buffer flushing. A trailing `$` is automatically added to match patterns at the end of the buffer. For example, `\d+\.` checks for a number followed by a dot at the end of the string.
Output result immediately	Toggle	The parameter appears when you select either Store in Input or Store in Context. This parameter allows you to output results immediately without using the Say Node and LLM Prompt token.
Store Detailed Results	Toggle	The parameter appears when you select either Store in Input or Store in Context, or when you enable Store Copy in Input. This parameter allows you to save detailed results of the LLM’s generated output. By default, the result is stored in the `promptResult` object. You can specify another value in the Context Key for the Result field to save it in the Context object, or in the Input Key for the Result to save it in the Input object. The object contains keys such as `result`, `finishReason`, and `usage`. It may also include `detailedResult` if completion models are used, as well as `firstChunk` and `lastChunk` in some streaming results, depending on the LLM provider.
Store Copy in Input	Toggle	The parameter appears when Stream to Output is selected. In addition to streaming the result to the output, store a copy in the Input object by specifying a value in the Input Key to store Result field.

Streaming ResultsIn Stream mode, LLM generates tokens and returns them one by one to Cognigy.AI to ensure low-latency responses. Cognigy.AI monitors delimiter tokens (Stream Buffer Flush Tokens), which serve as markers indicating when to output the token buffer. These tokens could be ., !, ?, or any other symbols that act as delimiters for complete logical statements. When Cognigy.AI detects one of these tokens, it promptly flushes the token buffer into the voice or text chat.The preconfigured overrides are listed in the table.

Regex	Description	Example
`\d+\.`	A number followed by a dot.	`26.08`
`\b(?:Dr\|Ms\|Mr\|Mrs\|Prof\|Sr\|Jr\|ca)\.`	Common abbreviations followed by a dot.	`Mr.`
`\b[A-Z]\.`	A single capital letter followed by a dot.	`M. Smith`
`\.\.\.`	Three dots used for omission.	`...`
`\b.\..\.`	Two-letter abbreviations.	`i.e.`, `e.g.`

Tool Settings

The process of setting up a tool is the same as for the AI Agent Node. See the example in the AI Agent Tool Settings section.

Parameter	Type	Description
Tool Choice	Selector	If supported by your LLM Model, this will determine how tools should be selected by the AI Agent: Auto — tools (or none) are automatically selected by the AI Agent when needed. Required — your AI Agent will always use one of its Tools. None — your AI Agent won’t use a tool.
Use Strict mode	Toggle	When the parameter is enabled, strict mode (if supported by the LLM provider) ensures that the arguments passed to a tool call precisely match the expected parameters. Enabling this feature can help prevent errors. However, it may cause a slight delay in the response, especially during the first call after making changes.

Image Handling

Parameter	Type	Description
Process Images	Toggle	Enable the AI Agent to read and understand images
attachments. Make sure that your LLM provider supports image processing; refer
to your provider’s documentation. In addition, make sure that attachments are
supported by and activated in your Endpoint, for example, Webchat.		Images
in Transcript	Selector	Configure how images older than the last turn are
handled to reduce token usage:

Minify — reduces the size of these images to 512x512px.
Drop — excludes the images.
Keep — sends the max size (this option consumes more tokens).

Limitations and token consumption depend on the LLM used. |

Error Handling

Parameter	Type	Description
Log to System Logs	Toggle	Log errors to the system logs. They can be viewed on the Logs page of your Project. The parameter is inactive by default.
Select Error Handling Approach	Select	You can select one of the Error Handling options: Stop Flow Execution — terminate the current Flow execution. Continue Flow Execution — allow the Flow to continue executing, bypassing the error and proceeding to the next steps. Go to Node — redirect the workflow to a specific Node in the Flow, which can be useful for error recovery or customized error handling.
Error Message (optional)	Text	The parameter appears when Continue Flow Execution is selected. Add an message to output if the LLM Prompt Node fails.
Select Flow	Select	The parameter appears when Go to Node is selected. Select a Flow from the available options.
Select Node	Select	The parameter appears when Go to Node is selected. Select a Node from the available options.

Custom Options

These settings are helpful if you need to use parameters that are not included in the LLM Prompt Node or if you need to overwrite existing ones.

Parameter	Type	Description
Custom Model Options	JSON	Additional parameters for the LLM model. You can specify individual parameters as well as entire functions. These parameters customize the behavior of the model, such as adjusting temperature, top_k, or presence_penalty. Note that if you use a parameter already set in the Node, for example, temperature, it will be overwritten. To view the full list of available parameters for your model, refer to the LLM provider’s API documentation. For example, OpenAI or Azure OpenAI. Examples: `{ "logprobs": true }` `{ "temperature": 0.7 }` `{ "model": "claude-3-5-sonnet-20240620" }` (see Forcing Model Versions)
Custom Request Options	JSON	Additional parameters for the LLM request. These parameters customize the request itself, such as setting parameters related to timeout, retries, or headers. For more information, refer to the LLM provider’s API documentation. Examples: - `{ "timeout": 5000 }` - `{ "headers": { "Authorization": "Bearer <token>" } }`

Forcing Model VersionsYou can force the LLM Prompt Node to use a specific model version by including it in the Custom Model Options. This means that the LLM Prompt Node will use the specified version of the language model instead of the default or any other available versions. This allows for more control over the behavior of the LLM Prompt Node, ensuring it utilizes the desired model version for generating prompts or responses.You can use models from any LLM provider supported by Cognigy, including those not yet directly integrated. However, you can only replace one model with another within the same provider.Let’s consider an example with the Anthropic provider: how to force the LLM Prompt Node to use the model version claude-3-sonnet-20240229, despite the LLM resource defaulting to the claude-3-5-sonnet-20240620 model:

Create an Anthropic LLM resource for Claude-1, for example, claude-3-5-sonnet-20240620.
Create a Flow and add an LLM Prompt Node to it.
In the LLM Prompt Node, select the model claude-3-5-sonnet-20240620 from the Large Language Model list.
Override the model selection. In the Custom Model Options field, specify the custom model options as follows: { "model": "claude-3-sonnet-20240229" }.
Click Save Node.

The LLM Prompt Node now utilizes the claude-3-sonnet-20240229 model.Below, you’ll find documentation for supported models:

Debugging Settings

When using the Interaction Panel, you can trigger two types of debug logs. These logs are only available when using the Interaction Panel and are not intended for production debugging. You can also combine both log types.

Parameter	Type	Description
Show Token Count	Toggle	Sends a debug message containing the input, output, and total token count. The message appears in the Interaction Panel when debug mode is enabled. Cognigy.AI uses the GPT-3 tokenizer algorithm, so actual token usage may vary depending on the model used. The parameter is inactive by default.
Log System Prompt & Completion	Toggle	Sends a debug message containing the system prompt sent to the LLM provider and the subsequent completion. The message appears in the Interaction Panel when debug mode is enabled. The parameter is inactive by default.
Log Tool Definitions	Toggle	Sends a debug message containing information about the configured AI Agent tools. The message appears in the Interaction Panel when debug mode is enabled. The parameter is inactive by default.
Log LLM Latency	Toggle	Sends a debug message containing key latency metrics for the request to the model, including the time taken for the first output and the total time to complete the request. The message appears in the Interaction Panel when debug mode is enabled. The parameter is inactive by default.
Send request logs to Webhook	Toggle	Sends the request sent to the LLM provider and the subsequent completion to a webhook service, including metadata, the request body, and custom logging data. With this parameter, you can use a webhook service to view detailed logs of the request to the LLM. The parameter is inactive by default.
Webhook URL	CognigyScript	Sets the URL of the webhook service to send the request logs to.
Custom Logging Data	CognigyScript	Sets custom data to send with the request to the webhook service.
Condition for Webhook Logging	CognigyScript	Sets the condition for the webhook logging.
Webhook Headers	Input fields	Sets the headers to send with the request to the webhook service. Use the Key and Value fields to enter a header. The Value field supports CognigyScript. After entering the header key, new empty Key and Value fields are automatically added, in case you need to add more headers. Alternatively, you can click Show JSON Editor and add input examples in the code field.

AI Agent Tool Settings

Tools are child Nodes of AI Agent Nodes. They define actions that can be taken by the AI Agent. If an AI Agent wants to execute the tool, the branch below the child Node is executed. At the end of a tool branch, it is advisable to use a Resolve Tool Action Node to return to the AI Agent. Clicking the Tool Node lets you define a tool, set its parameters, and allows debugging by enabling detailed messages about the tool’s execution.

Tool

Parameter	Type	Description
Tool ID	CognigyScript	Provide a meaningful name as a Tool ID. This ID can contain only letters, numbers, underscores (`_`), or dashes (`-`). For example, `update_user-1`.
Description	CognigyScript	Provide a detailed description of what the tool does, when it should be used, and its parameters.

Parameters

Configure the parameters that will be collected by the AI Agent before the tool is called. You can switch between the Graphical and JSON editors. When editing the JSON, follow the JSON Schema specification.

Parameter	Type	Description
Use Parameters	Toggle	Activate this toggle to add parameters in addition to the tool name and description. The AI Agent will collect all data it needs and call a Tool with these parameters filled as arguments. These values can be accessed directly in the `input.aiAgent.toolArgs` object.
Name	Text	Specify the name of the parameter. The name should be clear and concise, and describe the purpose of the parameter.
Type	Selector	Select a type of the parameter: String — a sequence of characters. For example, `"hello"`, `"123"`. Number — a numerical value, which can be either an integer (for example,`5`) or a floating point number (for example, `3.14`). Boolean — a logical value representing `true` or `false`. Array — a collection of elements, which can contain multiple values of any type. For example, `["apple", "banana", "cherry"]`. Object — a collection of key-value pairs, where each key is a string and the value can be of any type. For example, `{"name": "John", "age": 30}`.
Description	CognigyScript	Explain what parameter means by providing a brief description of the parameter’s usage.
Enum (optional)	Enum	Define a set of values that the parameter can accept. The enum restricts the input to one of the specified values, ensuring only valid options are chosen. The enum is only available for string-type parameters in the Graphical editor. For other types, use the JSON editor. May not be supported by all LLM providers.
Add Parameter	Button	Add a new parameter.

Debug Settings

Parameter	Type	Description
Debug Message when called	Toggle	Enable the output of a debug message when the tool is called to provide detailed information about the tool call.

Advanced

Parameter	Type	Description
Condition	CognigyScript	The tool will be enabled only if the condition is evaluated as true. If false, the tool isn’t part of the AI Agent’s Tools within this execution. For example, when using the `unlock_account` tool, you can specify a condition like `context.accountStatus === "locked"`. This checks the value in the context, and if it is missing or different, the tool will not be enabled.

AI Agent MCP Tool Settings

MCP Tool Nodes are child Nodes of AI Agent Nodes. The MCP Tool Nodes connect to a remote MCP server to load tools that the AI Agent can execute. If an AI Agent wants to execute one of the loaded tools, the branch below the MCP Tool Node is triggered. Clicking the MCP Tool Node lets you define the connection, filter loaded tools, and allows debugging by enabling detailed messages about the tool’s execution.

MCP Tool

Parameter	Type	Description
Name	CognigyScript	Provide a name for the MCP connection. This name helps you identify the source of the loaded tool.
MCP Server SSE URL	CognigyScript	Provide the URL to an SSE (Server-Sent Events) endpoint from a remote MCP server. Ensure that you connect only to trusted MCP servers.
Timeout	Slider	Set the timeout time for the MCP connection in seconds.

Debug Settings

Parameter	Type	Description
Debug Loaded Tools	Toggle	Enable this parameter to display a debug message listing all tools loaded from the MCP server. The debug message also includes tools filtered out in the Advanced section. This parameter shows whether tools were loaded from the cache or directly from the MCP server.
Debug with Parameters	Toggle	Enable this parameter to include the Tool Parameters in the debug message.
Debug calling Tool	Toggle	Enable the output of a debug message when the tool is called to provide detailed information about the tool call.

Advanced

Parameter	Type	Description
Cache Tools	Toggle	Disables caching of loaded tools while developing. Ensure that caching is enabled in production for performance reasons. The caching time is 10 minutes. In debug mode, you can verify whether the cache was used. To do this, make sure Debug Loaded Tools is enabled. For more information, see the Debug Settings section.
Condition	CognigyScript	Sets the condition under which the tool will be activated. If the condition is evaluated as false, the tool isn’t part of the AI Agent’s Tools during execution. For example, when using the `unlock_account` tool, you can specify a condition like `context.accountStatus === "locked"`. This checks the value in the context, and if it is missing or different, the tool will not be enabled.
Tool Filter	Select	Controls if tools should be excluded from execution. You can select one of the following options: None — no tool filtering is applied, and all tools are available for execution. This option is selected by default. Whitelist — only tools on the list are allowed for execution, while all other tools are excluded. Blacklist — tools on the list are excluded from execution, while all other tools remain available.
Blacklist	CognigyScript	This parameter appears if you select Blacklist in Tool Filter. Specify the tools that should be blocked from execution. Specify only one tool per field.
Whitelist	CognigyScript	This parameter appears if you select Whitelist in Tool Filter. Specify the tools you want to allow for execution. Specify only one tool per field.
Custom Headers	-	Sets custom authentication headers to send with the request to the MCP server. Use the Key and Value fields to enter a header. The Value field supports CognigyScript. After entering the header key, new empty Key and Value fields are automatically added, in case you need to add more headers. Alternatively, you can click Show JSON Editor and enter the headers in the code field.

Call MCP Tool Settings

In the Flow editor, when you add an MCP Tool Node, a Call MCP Tool Node is automatically created below it. These two Nodes work together to define and execute the chosen tool. The Call MCP Tool Node sets the actual execution point of the chosen tool. This way, you can verify or modify teh tool call arguments in the input.aiAgent.toolArgs object, or add a Say Node before the tool call. When the Call MCP Tool Node is executed, the tool call is sent to the remote MCP server, where the Tool is executed remotely with any arguments set by the AI Agent. To return the tool result to the AI Agent, the Resolve Immediately setting can be enabled to send the full result returned from the remote MCP server to the AI Agent. As an alternative, use a Resolve Tool Action Node to return a specific result to the AI Agent.

Call MCP Tool

Parameter	Type	Description
Resolve Immediately	Toggle	Enable this parameter to immediately resolve the tool action with the full result as the tool answer.

Storage Options

Parameter	Type	Description
How to handle the result	Select	Determine how to handle the MCP tool call result: Store in Input — stores the result in the Input object. Store in Context — stores the result in the Context object.
Input Key to store Result	CognigyScript	The parameter appears when Store in Input is selected. The result is stored in the `input.aiAgent.toolResult` object by default. You can specify another value, but the MCP Tool Result Token won’t work if the value is changed.
Context Key to store Result	CognigyScript	The parameter appears when Store in Context is selected. The result is stored in the `context.aiAgent.toolResult` object by default.

Debug Settings

Parameter	Type	Description
Debug Tool Result	Toggle	Enable the output of a debug message with the tool call result after a successful call.

Examples

AI Agent Tool

In this example, the unlock_account tool unlocks a user account by providing the email and specifying the reason for the unlocking. Parameter configuration in JSON:

{
  "type": "object",
  "properties": {
    "email": {
      "type": "string",
      "description": "User's login email for their account."
    }
  },
  "required": ["email"],
  "additionalProperties": false
}

where:

type — the type for a tool parameter schema, which must always be object.
properties — defines the parameters for the tool configuration:
- email — a required tool parameter for unlocking the account.
  - type — defines the data type for the tool parameter.
  - description — a brief explanation of what the property represents.
required — lists email as a required parameter, ensuring that this value is always provided when the tool is called.
additionalProperties — ensures that the input contains only the email tool parameter, and no others are allowed.

AI Agent MCP Tool and Call MCP Tool

Use Zapier’s Remote MCP server

You can create a custom MCP server with personalized tools by using one of the provided SDKs. For a quicker setup, you can use a third-party provider. For example, Zapier allows you to configure your MCP server, which can be connected to multiple application APIs. To use Zapier as a remote MCP server, follow these steps:

Log in to your Zapier account, go to the MCP settings page, and configure your MCP server.
Copy the SSE URL and paste it into the MCP Server SSE URL field of your MCP Tool Node.
In the Zapier MCP settings, create an action to connect to various APIs. For example, you can create a Zapier action to automatically generate a Google Doc.

Once the setup is complete, the configured MCP Actions will be loaded when the AI Agent is executed. You will see the following debug message in the Interaction Panel, indicating the result of the tool call after a successful execution:

AI Agent: MCP Tool
Fetched tools from MCP Tool "zapier"

- google_docs_create_document_from_: Create a new document from text. Also supports limited HTML.
  Parameters:
  - title (string): Document Name
  - file (string): Document Content

More Information

¹: Note that not all LLM models support streaming.
